• Dimension(W×D×H) : 620×410×870mm
• Power source : AC 220V 50/60Hz 2.5A
• Weight : 19.5kg
• Distinguished Features
6 different types of flasks are attachable (from 50ml to 3000㎖)
Digital speed control
Digital R.P.M Display / Speed control range : 20~280 R.P.M
Vertical type condenser
Digital interior temperature measure and display
(It catches the temperature changes caused by the interior
pressure drops)
Motorized UP- DOWN control switch
Easy to utilize standard distillation solution
Included Water bath HS-3001(PTFE coating)
• Heater : 1000W / Bath Material : SUS304 / Weight : 2.8kg
• Bath Dimension(φ×H)mm : 245×120(Capacity:4.3ℓ)
• Required Power Source : AC 220V 50/60Hz 3.5A
• Distinguished Features
If the amount of water goes down under the certain threshold
in the heating bath, the system automatically turns off its power
for the safety purpose
• Temp.Control range : Amb.~180℃
• Temp.Setting/Display : Digital control(controlled by the main
controller)
※ Double jacketed bath body (Safe to touch) | | |
