• Technical features
- 100% oil-free transfer
- Pure transfer, evacuation and compression
- Highly compatible with vapors and condensation
- Chemically-resistant
- Therefore suitable for highly aggressive and corrosive gases or
vapors
- Maintenance-free
- Environmentally friendly
• Technical data |
| |
|
Delivery(l/min)1 |
30 |
|
Ultimate vacuum (mbar) |
8.5 |
|
Connectors for tube (mm) |
OD 10 |
|
Voltage / Frequency |
230V/50Hz |
|
Power P1 |
(A)150W (B)120W |
|
Operating current |
0.5A |
|
Weight |
(A)10kg (B)8.5kg |
| Dimensions(LⅩHⅩW)mm |
(A)290/190/235
(B)280/230/130 |
| Material |
PE | | | |
